|Corrosion and Chemical Resistance
ChinaGrate molded grating is manufactured with continuous glass fiber strand
wetted thoroughly with premium grade polyester resin. Such inherent characteristics
ensure excellent corrosion resistance over a wide PH range - both acidic
Great Tensile Strength
Three-step continuous fiberglass strand alternating layers and ultimate
one-piece construction distributes loads to bi-directional bars for greater
metallic grating which will deform and need replacement, impact resistance
of fiberglass grating allows repeated deflections of fiberglass grating
without permanent deformation.
All ChinaGrate resin systems have a class 1 flame spread rating of 25
or less per ASTM E - 84.
ChinaGrate molded grating is ideally suited in electrically hazardous
locations. Its inherent property reduces the risk of electrical shock
by acting as an insulator between conductive materials.
ChinaGrate has three types of surface systems to offer maximum slip resistance
for most application. The build-in concave surface offer adequate protection,
and secondary silica grit or integral silica grit surface will provide
superior protection and last longer due to wear and tear.
ChinaGrate can be used in sensitive applications where the inherent magnetic
properties of metallic grating would prove lethal.
ChinaGrate is ideally suited for many applications where sparks can trigger
explosion or fire due to build-up of combustible gases.
Beautiful and Easy Maintenance
Maintenance freedom from painting and/or coating is achieved, not only
by the inherent corrosion/rust resistance, but also by the molded-in color
and ultraviolet resistance character.
Easy Installation and Fabrication
ChinaGrate molded grating weights about one-fourth of steel grating. During
installation or fabrication, a full panel can be easily lifted or moved
by two persons, and cut with eased using regular saw without expensive
tools or industrial-grade equipments.
